The cable color here refers to the color of cable supplied. If cable of other manufacturers is used,
the cable color may differ, and the actual cable you purchased shall prevail.
For type IV and type V, they have a 12-pin power and I/O interface, and their pin definition is
shown in Table 1-4.
CameraLink Area Scan Camera·User Manual
Table 1-3 Pin Definition (Type II and Type III)
No. Signal
1 GND
2 DC_PWR
3 TX485+
4 TX485-
5 GND_IO
6 RX485+
7 RX485-
8 232_RXD
9 232_TXD
OPTO_G
10
ND
OPTO_O
11
UT
12 OPTO_IN
I/O Signal Description
Source
Line 2 signal Camera power
ground supply ground
Camera power
--
supply
-- TX485+
-- TX485-
Line 0 and
Opto-isolated
line 1 signal
signal ground
ground
-- RX485+
-- RX485-
-- RS232_RXD
-- RS232_TXD
Line 2 signal
Input or output
line
Line 1 signal Opto-isolated
line output
Line 0 signal Opto-isolated
line input
4
Color
Black
Red
White/Blue
White/Green
Grey
White
Brown
Orange
Blue
Green
Purple
Yellow
