Figure 8-21 Set Saturation
In the format of Bayer, the color camera does not have saturation function.

8.14 Set Sharpness

The camera supports sharpness function that can adjust the sharpness level of the image edge,
and this function is disabled by default. You can set sharpness as shown below.
Steps:
1. Click Analog Control > Sharpness Enable.
2. Enable Sharpness Enable.
3. Enter proper value in Sharpness according to actual demands, and its range is from 0 to 100.
Figure 8-22 Set Sharpness

8.15 Set Channel Correct Mode

The channel correction function is used to solve the differences among taps. You can set channel
correct mode as shown below.
Steps:
1. Click Analog Control > Channel Correct Mode.
2. Select Active Mode or Passive Mode as Channel Correct Mode.
Figure 8-23 Set Channel Correct Mode
