3.2 Indicator Description

The camera has different types of indicator with varied models, including camera indicator and
CoaXPress linking indicator. For type I and type II cameras, they have camera indicator only. For
other types of cameras, they both have camera indicator and CoaXPress linking indicator.

3.2.1 Camera Indicator Status

The camera indicator is used to display different camera statuses.
When the indicator is flashing slowly, its unlit interval is about 1 s.
No. Status
1 Unlit
2 Solid blue
3 Rapid flashing blue
4 Slow flashing blue
Slow flashing blue and red in
5
alternative

3.2.2 CoaXPress Linking Indicator Status

The CoaXPress linking indicator is used to display CoaXPress linking connection status via
CoaXPress cable. For type III and type IV cameras, refer to the Table 3-3 for the status of CoaXPress
linking indicator.
When the indicator is flashing rapidly, flashing slowly, or flashing very slowly, its unlit interval is
0.08 s, 1 s, and 2 s respectively.
Table 3-3 CoaXPress Linking Indicator (Type III and Type IV Cameras)
No. Status
1 Unlit
2 Solid green
3 Rapid flashing green
CoaXPress Area Scan Camera
Table 3-2 Camera Indicator
Description
The camera is powered off.
There is no data transmission, or data transmission
exception occurs after camera starts up.
The camera is acquiring images in continuous mode.
The camera is acquiring images in trigger mode.
The camera firmware is updating.
Description
No CoaXPress linking connected, or connection error
occurs.
CoaXPress linking connected without data transmission,
or data transmission error occurs (e.g. CRC error).
The camera is acquiring images in continuous mode.
