Chapter 6. Terminal Menu and System Control
»» Trap Transmission
»» Authen Trap
Transmission
»» Traps Destination
IP Address
Community
Trap Filtering
Station Type
»» DS1 Current Perf TD
Current ES Thrsh
Current SES Thrsh
Current SEFS Thrsh
Current UAS Thrsh
6-10
Write security: 3; Read security: 5
Enables and disables SNMP trap transmission.
Write security: 3; Read security: 5
Enables and disables the authentication failure trap.
Write security: 3; Read security: 5
Defines the destination for SNMP traps as follows:
Identifies the IP address to which the network manager sends traps.
Defines the community name for trap destinations. This name must match
the community name defined at the network management station.
Sets the minimum severity level required for a system event to generate an
SNMP trap.
If a trap event occurs and if the trap's severity level is equal to or more severe
than the trap type's current threshold setting, that event is sent as an SNMP
trap. (Refer to the ATLAS 810
verity levels.) You can set the following threshold levels for the available se-
lections: disabled, critical, major, minor, warning, normal, and info.
Trap packets destined for the T-Watch GUI-based management station re-
quire ".ADLP ADDRESS" to be appended to the Community Name. Defin-
ing the Station Type to "T-Watch Mgmt" will automatically update this field
within the SNMP trap packet before sending it to the management station.
Defining the Station Type to "Normal" will deliver the SNMP trap packet
with the Community Name unchanged.
Defines performance threshold values for DS1 Line and Path statistics re-
corded in a 15-minute interval. If a statistic value exceeds its threshold value,
then the corresponding Alert Trap will be sent if the alert event is armed and
Alert Traps are enabled. These thresholds apply to all DS1 interfaces in the
system.
The DS1 performance monitor Threshold Value for the Current 15 minute
Errored Seconds (ES) parameter. The default value is 65 for an approximate
BER level of 10E-5.
The DS1 performance monitor Threshold Value for the Current 15 minute
Severely Errored Seconds (SES) parameter. The default value is 10 for an ap-
proximate BER level of 10E-5.
The DS1 performance monitor Threshold Value for the Current 15 minute
Severely Errored Framing Seconds (SEFS) parameter. The default value is 2
for an approximate BER level of 10E-5.
The DS1 performance monitor Threshold Value for the Current 15 minute
Unavailable Seconds (UAS) parameter. The default value is 10 for an ap-
proximate BER level of 10E-5.
PLUS
ATLAS 810
PLUS
MIB for a listing of all traps and their se-
User Manual
61200266L1-1
