ADTRAN ATLAS 810 Plus User Manual page 71

»» Transfer Method
»» TFTP Server IP
Address
»» TFTP Server
Filename
»» Current Transfer
Status
»» Previous Transfer
Status
»» Load and Use Config Write security: 3; Read security: 5
61200266L1-1
To support these transfers, ADTRAN delivers a TFTP program with
PLUS
ATLAS 810 called TFTP Server. You can configure any PC running Mi-
crosoft Windows with this software, and store a configuration file. See TFTP
Server on page 12-10 for details on how to use TFTP Server.
Before using Config Transfer, the ATLAS 810
valid IP address, subnet mask, and default gateway (if required),
and should be connected to an Ethernet network.
Only one configuration transfer session (upload or download) can be active
at a time. The TCP/IP parameters are not saved or overwritten as part of an
PLUS
ATLAS 810 unit's transferred configuration; this way, identical config-
urations can be sent to multiple units.
Write security: 3; Read security: 5
Displays the method used to transfer the configuration file to or from a
server. Currently, you must use TFTP.
Write security: 3; Read security: 5
Specifies the IP address of the TFTP Server. Get this number from your sys-
tem administrator.
Write security: 3; Read security: 5
Defines the name of the configuration file that you transfer to or retrieve
from the TFTP Server. The default name is
name.
Read security: 5
Indicates the current status of the update.
Read security: 5
Indicates the status of the previous update.
Retrieves the configuration file specified in the
from the server. To start this command, enter
If you execute Load and Use Config, the ATLAS 810
retrieves the configuration file, reboots, then restarts using the new
configuration.
ATLAS 810
Chapter 6. Terminal Menu and System Control
atlas.cfg
TFTP Server Filename
to begin or enter
Y
PLUS
User Manual
PLUS
should have a
, but you can edit this
field
to cancel.
N
PLUS
6-19
