Chapter 1

PRODUCT OVERVIEW

ATLAS 810 PLUS BASE UNIT
61200266L1-1
Introduction
PLUS
The ATLAS 810 is a modular, highly scalable platform that provides ro-
bust solutions for the wide area communication needs of medium-to-large
corporations and network access providers. ATLAS is an Integrated Access
System with the most extensive support of dedicated bandwidth manage-
ment and access switching in the industry.
PLUS
The ATLAS 810 is a high performance version of the ATLAS 800
PLUS
The ATLAS 810 contains a high-performance CPU and powerful com-
munications drivers which allow the support of optional applications such
as frame relay.
PLUS
With the ATLAS 810
applications into a single platform while optimizing wide area bandwidth
and reducing equipment costs. The ATLAS 810
chassis' eight expansion slots allow for a variety of modules, making it one
of the most versatile access systems on the market. With the appropriate
modules installed, the ATLAS 810
• A Frame Relay Switch
• A Digital Access Cross-Connect System (DACS)
• A T1 Bandwidth Manager
• An ISDN Access Switch
• A Remote Access Manager
PLUS
The ATLAS 810 architecture includes a packet switching and a circuit
switching bussing scheme. The result is a highly scalable system capable of
supporting bandwidth requirements up to 34 T1/E1 or Primary Rate ISDN
(PRI) circuits. Designed for standalone or rackmount installations, the
PLUS
ATLAS 810 Base Unit provides two network interfaces, each indepen-
dently configurable for T1, DSX-1, or PRI operation. Eight expansion slots
accommodate hot-swappable modules for a variety of applications. A
10BaseT connection for remote access and network management is standard
PLUS
with the ATLAS 810
PLUS
ATLAS 810
, you can consolidate your voice, data, and video
PLUS
PLUS
functions as follows:
Base Unit.
User Manual
PLUS
.
architecture and the
1-1
