» Out#Rej
»» Reject Number
»» Data 64K, Data 56K,
Audio, and Speech
» Ifce Config
USER TERM
>
» Slot/Svc, Port/PEP
61200266L1-1
Write security: 3; Read security: 5
Defines the parameters for the outgoing calls that ATLAS will not send to
the Network.
Identifies which numbers this endpoint will not pass on toward the Net-
work (PSTN). The reject list may consist of multiple entries. The reject list
may be used to more easily specify the call filtering desired. The "wild
cards" are identical as in Outgoing Call Accept.
The Reject list takes precedence over the Accept list. For example,
1-900-$ rejects all 1-900 long distance calls, and 1-$ rejects all long
distance calls.
Rejects outgoing calls based on call type. For example, setting the reject
number to $, Digital 56/64 to enabled, and Audio and Speech to disabled,
rejects all digital calls while not rejecting analog calls.
This list may remain blank if the Accept list meets desired filtering.
Sets configuration parameters for the endpoint. These parameters vary by
the type of port selected. For detailed information on the interface configu-
ration, refer to Interface Configurations on page 9-10.
This menu allows you to define option parameters for ports which termi-
nate a connection from user equipment. In this case, ATLAS 810
ing as the Network.
In applications where two ATLAS units are used in a point-to-point
configuration, a port in the ATLAS at one end acts as the Network
(set up as a User termination), while the ATLAS at the opposite end
terminates a Network connection.
Write security: 3; Read security: 5
Selects the ATLAS slot and port that terminate a User connection. (The user
selects from a list of option modules/ports.)
More than one endpoint may be associated with a particular port. If
a T1 port is connected to a channel bank with analog voice cards,
each DS0 or a group of DS0s may have a different phone number.
These numbers constitute multiple endpoints over a single physical
port.
ATLAS 810
Chapter 9. Dial Plan Terminal Menu
PLUS
User Manual
PLUS
is act-
9-5
