» Number Type
Templates
»» #
»» Pattern
» Automatic
Routeback
Rejection
»» #
»» Prefix
»» Pattern
»» Number Typ
» Global Tone Type
61200266L1-1
Write security: 1; Read security: 5
Sets call type patterns. ISDN interfaces require that a number type be sent
over the D channel when a call is sent or received. A normal RBS trunk does
not send a type designator, but uses prefixes instead. For example, "1 +"
prefix is a national long distance call type while a "011 +" prefix is an inter-
national long distance call type. These templates form a table to permit
ATLAS to translate the RBS prefix into a call type for ISDN and vice-versa.
Denotes an Entry Number (MAX 50). Press INS/DEL to insert/delete any en-
try.
Modifies an entry when you press Enter (MAX 40).
For example, 1+(NXX) NXX - XXXX would be a pattern for a normal long
distance call. Note that the symbols ( ), +, - and space are not required and
are only used to improve readability.
The ATLAS default templates should cover all applications and
should not need to be added to by the user except for very rare
circumstances.
Write security: 1; Read security: 5
When enabled, Automatic Routeback Rejection prevents calls which
enter through Network termination interfaces from being forwarded out
another network interface. Such an event could happen if an incoming call
specifies a number that has no endpoint configured to accept it and another
network interface has a call acceptance entry which could accept it (such as
$). Without automatic rejection, such a call would be forwarded back to the
Network. The Network would in turn resend the call to the unit until all
incoming resources are consumed.
Denotes an Entry Number (MAX 50). Press INS/DEL to insert/delete any en-
try.
Sets the prefix for the number type. Only digits 0 and 1 are allowed (MAX 6).
Modifies an entry when you press Enter (MAX 40).
Lists valid selections when you press Enter.
Use extreme caution when disabling Automatic Routeback
Rejection.
Specifies the dialing digit tone encoding to be used throughout the entire
system.
ATLAS 810
Chapter 9. Dial Plan Terminal Menu
PLUS
User Manual
9-9
