Chapter 9. Dial Plan Terminal Menu
» Sig
» In#Accept
»» Src ID
»» Accept Number
9-6
Write security: 3; Read security: 5
(User Selection - RBS; PRI) Defines the type of signaling being used for this
connection (endpoint). Select RBS for a T1 using Robbed Bit Signaling,
NFAS for a Primary Rate ISDN interface using Non-Facility Associated Sig-
naling, and PRI for a Primary Rate ISDN interface. This selection is only
necessary if a T1/PRI is selected as the Slot/Port type.
Write security: 3; Read security: 5
Defines the parameters for incoming calls that ATLAS 810
the Network.
Write Security: 3 Read Security: 5
(Source ID) Identifies the ID of the call sources from which this endpoint
accepts calls. This field simplifies the creation of a Dial Plan in applications
where the criterion for switching calls to a certain endpoint is a function of
which endpoint originated the call. Source ID may be entered with the
usual wild card entries (except $).
X = any digit 0—9
[1,3,5] = any of these digits
Default value = 0. The default ID for all Source endpoints and all accept
numbers is 0. This results in all calls being routed based on the dialed num-
ber.
Write security: 3; Read security: 5
Designates which numbers this endpoint will accept (terminate) from the
Network (PSTN). The accept list may consist of multiple entries. The num-
bers are defined using the following wild cards:
X = Any single digit
N = Any single digit 2—9
$ = Any number of digits of any value
9 = This specific number
[1,2,3...] = A single digit in this group
For example, 963-8000 would be a specific incoming number that would be
accepted by this endpoint. If this endpoint consisted of a T1 with multiple
DS0s, a "hunt" group for 963-8000 would be formed. The entry $ would ac-
cept any call.
Any specific entry will take precedence over a wild card. For
example, if endpoint "A" was designated as $ while endpoint "B"
accepted 963-800X, then an incoming call to 963-800X would
only be accepted by endpoint "B."
PLUS
ATLAS 810 User Manual
PLUS
accepts from
61200266L1-1
