General technical data

AC line supply (L1, L2, L3):
Supply voltage 200-240 V units
Supply voltage 380-500 V units
Supply voltage 525-600 V units
Supply voltage 525-690 V units
Supply frequency
See the section on special conditions in the Design Guide
Max. imbalance of supply voltage:
VLT 5001-5011, 380-500 V and 525-600 V and VLT 5001-5006, 200-240 V
VLT 5016-5062, 380-500 V and 525-600 V and VLT 5008-5027, 200-240 V
VLT 5072-5500, 380-500 V and VLT 5032-5052, 200-240 V
VLT 5075-5250, 525-600 V
True Power factor ( )
Displacement Power Factor (cos )
No. of switches on supply input L1, L2, L3
Max. shortcircuit rating
VLT output data (U, V, W):
Output voltage
Output frequency VLT 5001-5027, 200-240 V
Output frequency VLT 5032-5052, 200-240 V
Output frequency VLT 5001-5052, 380-500 V
Output frequency VLT 5062-5302, 380-500 V
Output frequency VLT 5352-5552, 380-500 V
Output frequency VLT 5001-5011, 525-600 V
Output frequency VLT 5016-5052, 525-600 V
Output frequency VLT 5062, 525-600 V
Output frequency VLT 5042-5302, 525-690 V
Output frequency VLT 5352-5602, 525-690 V
Rated motor voltage, 200-240 V units
Rated motor voltage, 380-500 V units
Rated motor voltage, 525-600 V units
Rated motor voltage, 525-690 V units
Rated motor frequency
Switching on output
Ramp times
Torque characteristics:
Starting torque, VLT 5001-5027, 200-240 V and VLT 5001-5552, 380-500 V
Starting torque, VLT 5032-5052, 200-240 V
Starting torque, VLT 5001-5062, 525-600 V
Starting torque, VLT 5042-5602, 525-690 V
Starting torque
Acceleration torque
Overload torque, VLT 5001-5027, 200-240 V and VLT 5001-5552, 380-500 V,
VLT 5001-5062, 525-600 V, and VLT 5042-5602, 525-690 V
6
®
VLT 5000 Series
3 x 200/208/220/230/240 V ±10%
3 x 380/400/415/440/460/500 V ±10%
3 x 525/550/575/600 V ±10%
3 x 525/550/575/600/690 V ±10%
±2.0% of rated supply voltage
±1.5% of rated supply voltage
±3.0% of rated supply voltage
±3.0% of rated supply voltage
380/400/415/440/460/480/500 V
MG.51.C5.22 - VLT is a registered Danfoss trademark.
48-62 Hz +/- 1 %
0.90 nominal at rated load
near unity (>0.98)
approx. 1 time/2 min.
100,000 A
0-100% of supply voltage
0-132 Hz, 0-1000 Hz
0-132 Hz, 0-450 Hz
0-132 Hz, 0-1000 Hz
0-132 Hz, 0-450 Hz
0-132 Hz, 0-300 Hz
0-132 Hz, 0-700 Hz
0-132 Hz, 0-1000 Hz
0-132 Hz, 0-450 Hz
0-132 Hz, 0-200 Hz
0-132 Hz, 0-150 Hz
200/208/220/230/240 V
525/550/575 V
525/550/575/690 V
50/60 Hz
Unlimited
0.05-3600 sec.
160% for 1 min.
150% for 1 min.
160% for 1 min.
160% for 1 min.
180% for 0.5 sec.
100%
160%
