Specifications

10.2 General Technical Data

Line power supply (L1, L2, L3)
Supply voltage
AC line voltage low/line voltage drop-out:
During low AC line voltage or a line drop-out, the adjustable frequency drive continues until the intermediate circuit voltage
drops below the minimum stop level, which corresponds typically to 15% below the adjustable frequency drive's lowest rated
supply voltage. Power-up and full torque cannot be expected at AC line voltage lower than 10% below the adjustable frequency
drive's lowest rated supply voltage.
Supply frequency
Max. temporary imbalance between line phases
True Power Factor (λ)
Displacement Power Factor (cos Φ) near unity
Switching on input supply L1, L2, L3 (power-ups)
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 480/600 V
Motor Output (U, V, W)
Output voltage
Output frequency
Switching on output
Ramp times
*
Dependent on voltage and power
Torque Characteristics
Starting torque (Constant torque)
Starting torque
10 10
Overload torque (Constant torque)
*) Percentage relates to the adjustable frequency drive's nominal torque
Cable lengths and cross-sections
Max. motor cable length, shielded/armored
Max. motor cable length, unshielded/unarmored
Max. cross-section to motor, line power, load sharing and brake
Maximum cross-section to control terminals, rigid wire
Maximum cross-section to control terminals, flexible cable
Maximum cross-section to control terminals, cable with enclosed core
Minimum cross-section to control terminals
*) Depending on voltage and power.
Digital inputs
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic '0' PNP
Voltage level, logic '1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
Input resistance, R
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
1)
Terminals 27 and 29 can also be programmed as output.
10-4
VLT
Instruction Manual
i
MG16D222 - VLT
®
HVAC Drive D-Frame
*
®
is a registered Danfoss trademark
380–480 V ±10%, 525–690 V±10%
50/60 Hz ±5%
3.0% of rated supply voltage
≥0.9 nominal at rated load
maximum one time/2 min
overvoltage category III/pollution degree 2
0–100% of supply voltage
maximum 110% for 60 s
maximum 135% up to 0.5 s*
maximum 110% for 60 s
500 ft [150 m]
1,000 ft [300 m]
2 2
0.0023 in [1.5 mm ]/16 AWG (2x0.75 mm
2
0.0016 in [1 mm
0.0008 in 2 [0.5 mm
0.00039 in2 [0.25 mm2]
18, 19, 27
(>0.98)
*
0–590 Hz
Unlimited
0.01–3,600 s
*
*
2
)
2
]/18 AWG
2 ]/20 AWG
4 (6)
1) 1)
, 29 , 32, 33
PNP or NPN
0–24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
approx. 4 kΩ
