tion of [Fwd/rev], which is only active in
Local operation.
NOTE
If no external stop function has been se-
lected and the [Stop] key has been selec-
ted as inactive, the motor can be started
and can only be stopped by disconnecting
the voltage to the motor.
Control panel - display read-outs
The display read-out state can be varied - see the list
below - depending on whether the adjustable frequen-
cy drive is in normal operation or is being programmed.
Display mode
In normal operation, up to 4 different operating varia-
bles can be indicated continuously: 1.1 and 1.2 and
1.3 and 2, and in line 4 the present operating status or
alarms and warnings that have arisen.
VAR 1.1 VAR 1.2 VAR 1.3
VAR 2
STATUS
Display mode - selection of read-outstate
There are three options in connection with the choice
of read-out state in the Display mode - I, II and III. The
choice of read-out state determines the number of op-
erating variables read out.
Read-out
I:
II:
state:
Line 1
Description for op-
Data value for 3
erating variable in
operating varia-
line 2
bles in line 1
The table below gives the units linked to the variables
in the first and second line of the display.
MG.51.C5.22 - VLT
is a registered Danfoss trademark.
Operating variable:
Reference
Reference
Feedback
Frequency
Frequency x scaling
Motor current
Torque
Power
Power
Output energy
Motor voltage
DC-link voltage
Motor thermal load
VLT thermal load
Hours run
Input status, dig. Input
Input status, analog terminal 53
Input status, analog terminal 54
Input status, analog terminal 60
Pulse reference
External reference
Status word
Brake effect/2 min.
Brake effect/sec.
Heat sink temp.
Alarm word
Control word
Warning word 1
Extended status word
Communication option card warning
RPM
RPM x scaling
LCP Display text
SETUP
Operating variables 1.1 and 1.2 and 1.3 in the first line,
1
and operating variable 2 in the second line are selec-
ted via parameter 009, 010, 011 and 012.
III:
Description for 3
operating varia-
bles in line 1
®
VLT
5000 Series
Unit:
[%]
[unit]
[unit]
[Hz]
[-]
[A]
[%]
[kW]
[HP]
[kWh]
[V]
[V]
[%]
[%]
[Hours]
[Binary code]
[V]
[V]
[mA]
[Hz]
[%]
[Hex]
[kW]
[kW]
[ºC]
[Hex]
[Hex]
[Hex]
[Hex]
[Hex]
-1
[min
]
[ - ]
[ - ]
73
