Danfoss VLT 5000 Series Instruction Manual page 41

Ordering numbers, Brake resistors, VLT 5001 -
5250 / 550 - 600 V
Standard brake resistors
Resistance
2
VLT [ohm]
3
797.0
5001
3
534.0
5002
3 398.0
5003
3
5004 267.0
3
199.0
5005
3
149.0
5006
3 107.0
5008
3
80.0
5011
3
53.4
5016
3 39.8
5022
3 32.0
5027
3
26.7
5032
3
19.9
5042
3 16.0
5052
3
13.3
5062
5
11.0
5075
5 8.2
5100
5 6.8
5125
5
5.6
5150
5
4.3
5200
5 3.3
5250
1) No Danfoss part number. Resistors must be ordered from another
vendor according to specifications.
2) Tolerance +/- 5%
3) 10% Duty Cycle, 120 second period
4) 40% Duty Cycle, 120 second period
5) 10% Duty Cycle, 300 second period
38
10% duty cycle
Code No.
Power
[kW]
0.11 *1)
0.16 *1)
0.22 *1)
0.32 *1)
0.44 *1)
0.58 *1)
0.80 *1)
1.09 *1)
1.60 *1)
2.19 *1)
2.70 *1)
3.21 *1)
4.38 *1)
5.40 *1)
6.56 *1)
8.16 *1)
10.88 *1)
13.60 *1)
16.32 *1)
21.77 *1)
27.21 *1)
®
VLT 5000 Series
40% duty cycle
Resistance
Power
2
[ohm] [kW]
797.0 0.44
534.0 0.64
398.0 0.88
267.0 1.28
199.0 1.75
149.0 2.33
107.0 3.21
80.0 4.38
53.4 6.42
39.8 8.75
32.0 10.80
26.7 12.84
19.9 17.51
16.0 21.59
13.3 26.26
See instruction MI.90.FX.YY for further information.
MG.51.C5.22 - VLT is a registered Danfoss trademark.
4
Code No.
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
*1)
