Tightening-up torques and screw sizes
The table shows the torque required when fitting ter-
minals to the adjustable frequency drive. For VLT
5001-5027 200-240 V, VLT 5001-5102 380-500 V and
VLT 5001-5062 525-600 V, the cables must be fas-
tened with screws. For VLT 5032-5052 200-240 V,
VLT 5122-5552 380-500 V, VLT 5042-5602 525-690
V, the cables must be fastened with bolts.
These figures apply to the following terminals:
VLT type
200-240 V
5001-5006
5008
5008-5011
5011-5022
31)
5016-5022
5027
5032-5052
380-500 V
5001-5011
5016-5022
5016-5027
5027-5042
3)
5032-5042
5052-5062
5072-5102
4)
5122-5302
5)
5352-5552
525-600 V
5001-5011
5016-5027
5032-5042
5052-5062
525-690 V
4)
5042-5352
5)
5402-5602
1) Brake terminals: 3,0 Nm, Nut: M6
2) Brake and load sharing: 14 Nm, M6 Allen screw
3) IP 54 with RFI - Line terminals 6 Nm, Screw: M6 - 5 mm Allen wrench
4) Load sharing and brake terminals: 9,5 Nm; Bolt M8
5) Brake terminals: 9,5 Nm; Bolt M8.
MG.51.C5.22 - VLT is a registered Danfoss trademark.
Line terminals
Motor terminals
Ground terminal
Brake resistor terminals
Load sharing
Torque [Nm] Screw/
Bolt size
0,6 M3
IP 20 1,8 M4
IP 54 1,8 M4
IP 20 3 M5
IP 54 3 M5
6 M6
11,3 M8 (bolt and stud)
0,6 M3
IP 20 1,8 M4
IP 54 1,8 M4
IP 20 3 M5
IP 54 3 M5
6 M6
IP 20 15 M6
2)
24 M8
IP 54
19 M10 bolt
19 M10 bolt (compression
lug)
0,6 M3
1,8 M4
3 M5
6 M6
19 M10 bolt
19 M10 bolt (compression
lug)
®
VLT 5000 Series
Nos. 91, 92, 93
L1, L2, L3
Nos. 96, 97, 98
U, V, W
No. 94, 95, 99
81, 82
88, 89
Tool
Slotted screw
Slotted screw
Slotted screw
4 mm Allen wrench
4 mm Allen wrench
4 mm Allen wrench
Slotted screw
Slotted screw
Slotted screw
4 mm Allen wrench
4 mm Allen wrench
5 mm Allen wrench
6 mm Allen wrench
8 mm Allen wrench
16 mm wrench
16 mm wrench
Slotted screw
Slotted screw
4 mm Allen wrench
5 mm Allen wrench
16 mm wrench
16 mm wrench
