Danfoss VLT 5000 Series Instruction Manual page 145

Digital input Bus
505-508
0
0
1
1
Logic or [3] is selected if the control command in ques-
tion is to be activated when a signal is given (active
signal = 1) either via a control word or via a digital input.
Digital input Bus
505-508
0
0
1
1
NOTE
Parameters 502-504 deal with stop func-
tions - see examples regarding 502
(coasting) below. Active stop command
"0".
Parameter 502 = Logic and
Digital input Bus
0 0
0 1
1 0
1 1
Parameter 502 = Logic or
Digital input Bus
0 0
0 1
1 0
1 1
506 Reversing
(REVERSING SELECT)
Value:
Digital input (DIGITAL INPUT)
Bus (SERIAL PORT)
Logic and (LOGIC AND)
Logic or (LOGIC OR)
Function:
See description under parameter 502.
= factory setting, () = display text, [] = value for use in communication via serial communication port
142
Control com-
mand
0 0
1 0
0 0
1 1
Control com-
mand
0 0
1 1
0 1
1 1
Control command
1 Coasting
0 Motor running
0 Motor running
0 Motor running
Control command
1 Coasting
1 Motor running
1 Motor running
0 Motor running
[0]
[1]
[2]
[3]
®
VLT 5000 Series
Description of choice:
See description under parameter 502.
509 Bus jog 1
(BUS JOG 1 FREQ.)
Value:
0.0 - parameter 202
Function:
This is where to set a fixed speed (jog) that is activated
via the serial communication port.
This function is the same as in parameter 213.
Description of choice:
The jog frequency f can be selected in the range
JOG
between f (parameter 201) and f
MIN
202).
510 Bus jog 2
(BUS JOG 2 FREQ.)
Value:
0.0 - parameter 202
Function:
This is where to set a fixed speed (jog) that is activated
via the serial communication port.
This function is the same as in parameter 213.
Description of choice:
The jog frequency f
can be selected in the range
JOG
between f (parameter 201) and f
MIN
202).
512 Telegram profile
(TELEGRAM PROFILE)
Value:
Fieldbus profile (FIELDBUS PROFILE)
FC Drive (FC DRIVE)
Function:
There is a choice of two different control word profiles.
Description of choice:
Select the desired control word profile.
MG.51.C5.22 - VLT is a registered Danfoss trademark.
10.0 Hz
(parameter
MAX
10.0 Hz
(parameter
MAX
[0]
[1]
