Danfoss VLT 5000 Series Instruction Manual page 226

PN
U Parameter
# description
300 Terminal 16, input
301 Terminal 17, input
302 Terminal 18 Start, input
303 Terminal 19, input
304 Terminal 27, input
305 Terminal 29, input
306 Terminal 32, input
307 Terminal 33, input
308 Terminal 53, analogue input voltage Reference
309 Terminal 53, min. scaling
310 Terminal 53, max. scaling
311 Terminal 54, analogue input voltage No operation
312 Terminal 54, min. scaling
313 Terminal 54, max. scaling
314 Terminal 60, analogue input current Reference
315 Terminal 60, min. scaling
316 Terminal 60, max. scaling
317 Time out
318 Function after time out
319 Terminal 42, output
320 Terminal 42, output, pulse scaling
321 Terminal 45, output
322 Terminal 45, output, pulse scaling
323 Relay 01, output
324 Relay 01, ON delay
325 Relay 01, OFF delay
326 Relay 04, output
327 Pulse reference, max. frequency
328 Pulse feedback, max. frequency
329 Encoder feedback pulse/rev.
330 Freeze reference/output function
345 Encoder loss timeout
346 Encoder loss function
357 Terminal 42, Output minimum scaling 0 %
358 Terminal 42, Output maximum scal-
ing
359 Terminal 45, Output minimum scaling 0 %
360 Terminal 45, Output maximum scal-
ing
361 Encoder loss threshold
MG.51.C5.22 - VLT is a registered Danfoss trademark.
Factory setting Range
Reset
Freeze reference
Start
Reversing
Coasting stop, inverse
Jog
Choice of setup, msb/speed up
Choice of setup, lsb/speed down
0.0 V 0.0 - 10.0 V
10.0 V 0.0 - 10.0 V
0.0 V 0.0 - 10.0 V
10.0 V 0.0 - 10.0 V
0.0 mA 0.0 - 20.0 mA
20.0 mA 0.0 - 20.0 mA
10 sec. 1 - 99 sec.
Off
0 - I Þ 0-20 mA
MAX
5000 Hz 1 - 32000 Hz
0 - f Þ 0-20 mA
MAX
5000 Hz 1 - 32000 Hz
Ready - no thermal warning
0.00 sec. 0.00 - 600 sec.
0.00 sec. 0.00 - 600 sec.
Ready - remote control
5000 Hz
25000 Hz
1024 pulses/rev. 1 - 4096 pulses/
rev.
No operation
1 sec. 0 - 60 sec
OFF
000 - 100%
100% 000 - 500%
000 - 100%
100% 000 - 500%
300% 000 - 600 %
®
VLT 5000 Series
Chang
es 4-Setup Conversion Data
during operation index
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes -1
Yes Yes -1
Yes Yes 0
Yes Yes -1
Yes Yes -1
Yes Yes 0
Yes Yes -4
Yes Yes -4
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes -2
Yes Yes -2
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes No 0
Yes Yes -1
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
Yes Yes 0
type
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
6
5
6
5
6
6
5
6
6
6
5
6
5
6
6
6
6
6
223
