Danfoss VLT 5000 Series Instruction Manual page 39

Ordering numbers, Brake resistors, VLT 5001 -
5552 / 380 - 500 V
Standard brake resistors
Resistance
VLT [ohm]
5001 620
5002 425
5003 310
5004 210
5005 150
5006 110
5008 80
5011 65
5016 40
5022 30
5027 25
5032 20
5042 15
5052 12
5062 9.8
5072 7.3
5102 5.7
2)
3.8
5122
2) 3.2
5152
2) 2.6
5202
2)
2.1
5252
2)
1.65
5302
2) 1.3
5352-5552
1. Order 2 pcs. Connect in parallel.
2. Resistors selected for 300 second cycle.
3. Rating fulfilled up to VLT 5452, the torque is reduced for VLT 5502 and VLT 5552.
See Instruction MI.90.FX.YY for further information.
36
10% duty cycle
Power Code No.
[kW]
0.065 175U1840
0.095 175U1841
0.250 175U1842
0.285 175U1843
0.430 175U1844
0.60 175U1845
0.85 175U1846
1.0 175U1847
1.8 175U1848
2.8 175U1849
3.5 175U1850
4.0 175U1851
4.8 175U1852
5.5 175U1853
15 175U2008
13 175U0069
15 175U0067
22 175U1960
27 175U1961
32 175U1962
39 175U1963
1)
56
2 x 175U1061
72 1) 3)
2 x 175U1062
®
VLT 5000 Series
40% duty cycle
Resistance Power
[ohm] [kW]
620 0.260
425 0.430
310 0.80
210 1.35
150 2.0
110 2.4
80 3.0
65 4.5
40 5.0
30 9.3
25 12.7
20 13.0
15 15.6
12 19.0
9.8 38.0
5.7 38.0
4.7 45.0
MG.51.C5.22 - VLT is a registered Danfoss trademark.
Code No.
175U1940
175U1941
175U1942
175U1943
175U1944
175U1945
175U1946
175U1947
175U1948
175U1949
175U1950
175U1951
175U1952
175U1953
175U2008
175U0068
175U0066
