Parameters - Technical functions and diagnostics

Parameter no. Description
Operating data
600 Operating hours
601 Hours run
602 kWh counter
603 No. of cut-ins
604 No. of overtemps
605 No. of overvoltages
Function:
These parameters can be read out via the serial com-
munication port and via the display in the parameters.
Description of choice:
Operating hours , parameter 600:
Indicates the number of hours in which the adjustable
frequency drive has been in operation.
The value is updated in the adjustable frequency drive
every hour and saved when the unit is turned off.
Hours run, parameter 601:
Indicates the number of hours in which the adjustable
frequency drive has been in operation since reset in
parameter 619.
The value is updated in the adjustable frequency drive
every hour and saved when the unit is turned off.
Parameter no. Description
Data log
606 Digital inputs
607 Control word
608 Status word
609 Reference
610 Feedback
611 Output frequency
612 Output voltage
613 Output current
614 DC link voltage
Function:
Via this parameter it is possible to see up to 20 data-
logs, where [0] is the latest log and [19] the oldest.
Each data-log is made every 160 ms as long as a start
signal has been given. If a stop signal is given, the lat-
est 20 data-logs will be saved and the values will be
available on the display. This is useful, e.g. when car-
rying out service after a trip.
= factory setting, () = display text, [] = value for use in communication via serial communication port
MG.51.C5.22 - VLT is a registered Danfoss trademark.
VLT
Display text
(OPERATING HOURS)
(RUNNING HOURS)
(KWH COUNTER)
(POWER UP's)
(OVER TEMP's)
(OVER VOLT'S)
kWh counter , parameter 602:
States the kW consumption of the motor as a mean
value over one hour, since the reset in parameter 618.
No. of cut-ins, parameter 603:
States the number of power-ups of the supply voltage
to the adjustable frequency drive.
No. of overtemps, parameter 604:
States the number of temperature faults there has
been on the adjustable frequency drive.
No. of overvoltages, parameter 605:
States the number of overvoltages there has been on
the adjustable frequency drive.
Display text
(LOG: DIGITAL INP)
(LOG: CONTROL WORD
(LOG: BUS STAT WD)
(LOG: REFERENCE)
(LOG: FEEDBACK)
(LOG: MOTOR FREQ.)
(LOG: MOTOR VOLT)
(LOG: MOTOR CURR.)
(LOG: DC LINK VOLT)
This parameter can be read out via the serial commu-
nication port or via the display.
Description of choice:
The data-log number is stated in square brackets: [1].
Data-logs are frozen if there is a trip and released
when the adjustable frequency drive is subsequently
reset.
Data-logging is active while the motor is running.
®
5000 Series
Unit Range
Hours 0 - 130,000.0
Hours 0 - 130,000.0
kWh 0 - 9999
Nos. 0 - 9999
Nos. 0 - 9999
Nos. 0 - 9999
Unit Range
Decimal 0 - 255
Decimal 0 - 65535
Decimal 0 - 65535
% 0 - 100
Par. 416 999,999.99
999,999.99
Hz. 0.0 - 999.9
Volt 50 - 1000
Amp 0.0 - 999.9
Volt 0.0 - 999.9
-
149
