Danfoss VLT 5000 Series Instruction Manual page 227

PN
U Parameter
# description
400 Brake function/overvoltage control
401 Brake resistor, ohm
402 Braking energy limit, kW
403 Power monitoring
404 Brake check
405 Reset function
406 Automatic restart time
407 Line Failure
408 Quick discharge
409 Trip delay torque
410 Trip delay inverter
411 Switching frequency
412 Output frequency dependent switching
frequency
413 Overmodulation function
414 Minimum feedback
415 Maximum feedback
416 Process unit
417 Speed PID proportional gain
418 Speed PID integration time
419 Speed PID differentiation time
420 Speed PID diff. gain ratio
421 Speed PID low-pass filter
422 U 0 voltage at 0 Hz
423 U 1 voltage
424 F 1 frequency
425 U 2 voltage
426 F 2 frequency
427 U 3 voltage
428 F 3 frequency
429 U 4 voltage
224
Factory setting
Off
Depends on the unit
Depends on the unit
On
Off
Manual reset
5 sec
No function
Not possible
Off
Depends on type of unit
Depends on type of unit
Not possible
On
0.000
1500.000
%
0.015
8 ms
30 ms
5.0
10 ms
20.0 V
parameter 103
parameter 104
parameter 103
parameter 104
parameter 103
parameter 104
parameter 103
MG.51.C5.22 - VLT
®
VLT 5000 Series
Change 4-Set-
Range s up
during operation
Yes No.
Yes No.
Yes No.
Yes No.
Yes No.
Yes Yes
0-10 sec Yes Yes
Yes Yes
Yes Yes
0-60 sec Yes Yes
0-35 sec Yes Yes
1.5-14 kHz Yes Yes
Yes Yes
Yes Yes
-100,000.000 Yes Yes
- FB
HIGH
FB - Yes Yes
LOW
100,000.000
Yes Yes
0.000 - 0.150 Yes Yes
2.00 - 999.99 Yes Yes
ms
0.00 - 200.00 Yes Yes
ms
5.0 - 50.0 Yes Yes
5 - 200 ms Yes Yes
0.0 - parame- Yes Yes
ter 103
0.0 - U Yes Yes
VLT, MAX
0.0 - parame- Yes Yes
ter 426
0.0 - U Yes Yes
VLT, MAX
par. 424 - par. Yes Yes
428
0.0 - U Yes Yes
VLT, MAX
par. 426 - par. Yes Yes
430
0.0 - U Yes Yes
VLT, MAX
is a registered Danfoss trademark.
Conver-
sion Data
index type
0 5
-1 6
2 6
0 5
0 5
0 5
0 5
0 5
0 5
0 5
0 5
2 6
0 5
-1 5
-3 4
-3 4
0 5
-3 6
-4 7
-4 6
-1 6
-4 6
-1 6
-1 6
-1 6
-1 6
-1 6
-1 6
-1 6
-1 6
