Danfoss VLT 5000 Series Instruction Manual page 38

Brake resistors, VLT 5001 - 5052 / 200 - 240 V
Standard brake resistors
10% duty cycle
Resistance Power
VLT [ohm] [kW]
5001 145 0.065
5002 90 0.095
5003 65 0.250
5004 50 0.285
5005 35 0.430
5006 25 0.8
5008 20 1.0
5011 15 1.8
5016 10 2.8
5022 7 4.0
5027 6 4.8
5032 4.7 6
5042 3.3 8
5052 2.7 10
See Instruction MI.90.FX.YY for further information.
Flatpack brake resistors for horizontal conveyors
VLT type Motor [kW]
5001 0.75
5001 0.75
5002 1.1
5002 1.1
5003 1.5
5004 2.2
5005 3
5005 3
5006 4
5008 5.5
5011 7.5
1. Order 2 pcs.
Mounting angle for flatpack resistor 100 W 175U0011
Mounting angle for flatpack resistor 200 W 175U0009
Mounting frame for 1 resistor narrow (slim bookstyle)
175U0002
Mounting frame for 2 resistors narrow (slim bookstyle)
175U0004
MG.51.C5.22 - VLT is a registered Danfoss trademark.
Code No. Resistance
[ohm]
175U1820 145
175U1821 90
175U1822 65
175U1823 50
175U1824 35
175U1825 25
175U1826 20
175U1827 15
175U1828 10
175U1829 7
175U1830 6
175U1954 Not available
175U1955 Not available
175U1956 Not available
Resistor [ohm] Size
150
150 100 W
150
150 200 W
100
100 100 W
100
100 200 W
72
72 200 W
50
47 200 W
35
35 200 W
72
35 200 W
50
25 200 W
40
20 200 W
27
13 200 W
Mounting frame for 2 resistors broad (wide bookstyle)
175U0003
See Instruction MI.50.BX.YY for further information.
®
VLT 5000 Series
40% duty cycle
Power Code No.
[kW]
0.260 175U1920
0.430 175U1921
0.80 175U1922
1.00 175U1923
1.35 175U1924
3.00 175U1925
3.50 175U1926
5.00 175U1927
9.0 175U1928
10.0 175U1929
12.7 175U1930
Not available Not available
Not available Not available
Not available Not available
Order number Max. duty cycle [%]
175U1005 14.0
175U0989 40.0
175U1006 8.0
175U0991 20.0
175U0992 16.0
175U0993 9.0
175U0994 5.5
1
12.0
2 x 175U0992
1 11.0
2 x 175U0993
1 6.5
2 x 175U0996
1
4.0
2 x 175U0995
35
