Electrical data

According to international requirements
Output current
Output (240 V)
Typical shaft output
Typical shaft output
Max. cable cross-section to motor,
brake and loadsharing [mm
Rated input current
Max. cable
cross-section power [mm
Max. pre-fuses
3)
Efficiency
Weight IP 20 EB Bookstyle
Weight IP 20 EB Compact [kg]
Weight IP 54 Compact
Power loss at
max. load.
Enclosure
1. For type of fuse see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
MG.51.C5.22 - VLT is a registered Danfoss trademark.
Bookstyle and Compact, Mains supply 3 x 200 -
240 V
VLT type 5001
I [A] 3.7
VLT,N
I (60 s) [A] 5.9
VLT, MAX
S [kVA] 1.5
VLT,N
P [kW] 0.75
VLT,N
P [HP] 1
VLT,N
4/10
2 2
]/[AWG] )
(200 V)I [A] 3.4
L,N
4/10
2 2
]/[AWG] )
1) 16/10
[-]/UL [A]
0.95
[kg] 7
8
[kg] 11.5
[W] 58
IP 20/
IP54
®
VLT 5000 Series
5002 5003 5004 5005
5.4 7.8 10.6 12.5
8.6 12.5 17 20
2.2 3.2 4.4 5.2
1.1 1.5 2.2 3.0
1.5 2 3 4
4/10 4/10 4/10 4/10
4.8 7.1 9.5 11.5
4/10 4/10 4/10 4/10
16/10 16/15 25/20 25/25
0.95 0.95 0.95 0.95
7 7 9 9
8 8 10 10
11.5 11.5 13.5 13.5
76 95 126 172
IP 20/ IP 20/ IP 20/ IP 20/
IP54 IP54 IP54 IP54
5006
15.2
24.3
6.3
3.7
5
4/10
14.5
4/10
35/30
0.95
9.5
10
13.5
194
IP 20/
IP54
