Contents
Introduction to VLT 3000 to VLT 5000 Converter
Software version ................................................................................................ 2
Introduction ........................................................................................................ 3
Configuration ...................................................................................................... 3
Setup of the converter software ........................................................................ 3
Bus connection .................................................................................................. 4
Mapping list ........................................................................................................ 5
1
MG.50.Q2.02 - VLT is a registered Danfoss trade mark
Advertisement
Related Manuals for Danfoss VLT 3000 Series
Summary of Contents for Danfoss VLT 3000 Series
-
Page 1: Table Of Contents
Introduction to VLT 3000 to VLT 5000 Converter Software version ....................2 Introduction ......................3 Configuration ...................... 3 Setup of the converter software ................ 3 Bus connection ....................4 Mapping list ......................5 MG.50.Q2.02 – VLT is a registered Danfoss trade mark... -
Page 2: Software Version
Option card software version: 17.1x Profibus DP Norm This manual can be used for the VLT 3000 to 5000 converter, software version 17.xx. The software version can be seen in VLT 5000 parameter 624. MG.50.Q2.02 – VLT is a registered Danfoss trade mark... -
Page 3: Introduction
Sinec L2 or a Siemens DP network. You communication between master and slave is can check your Profibus network either by the VLT established. 3000 or by the master. MG.50.Q2.02 – VLT is a registered Danfoss trade mark... -
Page 4: Bus Connection
VLT 5000 as the VLT 3000. Bus connection NOTE: VLT 5000 has other physical connections compared to VLT 3000. VLT 3000 VLT 5000 MG.50.Q2.02 – VLT is a registered Danfoss trade mark... -
Page 5: Mapping List
440 Process PID Proportional Gain 122 Integral Time 441 Process PID Integral Time 123 Differentiation Time 442 Process PID Differentiation Time 124 Low Pass Filter 444 Process PID Low Pass Filter MG.50.Q2.02 – VLT is a registered Danfoss trade mark... - Page 6 Control" in parameter 323 and 326 the functionality of this parameter is control of the cut-in frequency for a mechanical brake 232 Current, Minimum Value 223 Warning: Low Current 233 Current, Delay Time 120 Start Delay Time MG.50.Q2.02 – VLT is a registered Danfoss trade mark...
