Danfoss VLT 5000 Series Instruction Manual page 225

PNU Parameter
# description
200 Output frequency range/direction Only clockwise, 0-132 Hz
201 Output frequency low limit
202 Output frequency high limit
203 Reference/feedback area
204 Minimum reference
205 Maximum reference
206 Ramp type
207 Ramp-up time 1
208 Ramp-down time 1
209 Ramp-up time 2
210 Ramp-down time 2
211 Jog ramp time
212 Quick stop ramp-down time
213 Jog frequency
214 Reference function
215 Preset reference 1
216 Preset reference 2
217 Preset reference 3
218 Preset reference 4
219 Catch up/slow down value
220
221 Torque limit for motor mode
222 Torque limit for regenerative op-
eration
223 Warning: Low current
224 Warning: High current
225 Warning: Low frequency
226 Warning: High frequency
227 Warning: Low feedback
228 Warning: High feedback
229 Frequency bypass, bandwidth
230 Frequency bypass 1
231 Frequency bypass 2
232 Frequency bypass 3
233 Frequency bypass 4
234 Motor phase monitor
222
Factory setting Range
0.0 Hz 0.0 - f
66 / 132 Hz f - par. 200
MIN
Min - max
0.000 -100,000.000-Ref
50.000 Ref
MIN
Linear
Depends on unit 0.05 - 3600
Depends on unit 0.05 - 3600
Depends on unit 0.05 - 3600
Depends on unit 0.05 - 3600
Depends on unit 0.05 - 3600
Depends on unit 0.05 - 3600
10.0 Hz 0.0 - par. 202
Sum
0.00 % - 100.00 - 100.00 %
0.00 % - 100.00 - 100.00 %
0.00 % - 100.00 - 100.00 %
0.00 % - 100.00 - 100.00 %
0.00 % 0.00 - 100 %
160 % 0.0 % - xxx %
160 % 0.0 % - xxx %
0.0 A 0.0 - par. 224
I Par. 223 - I
VLT,MAX
0.0 Hz 0.0 - par. 226
132.0 Hz Par. 225 - par. 202
-4000.000 -100,000.000 - par. 228 Yes
4000.000 Par. 227 - 100,000.000
OFF 0 - 100 %
0.0 Hz 0.0 - par. 200
0.0 Hz 0.0 - par. 200
0.0 Hz 0.0 - par. 200
0.0 Hz 0.0 - par. 200
Enable
MG.51.C5.22 - VLT
®
VLT 5000 Series
Changes 4-Setup
during operation
No
Yes
MAX
Yes
Yes
Yes
MAX
-100,000.000 Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
VLT,MAX
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
is a registered Danfoss trademark.
Conver-
sion Data
index type
Yes 0 5
Yes -1 6
Yes -1 6
Yes 0 5
Yes -3 4
Yes -3 4
Yes 0 5
Yes -2 7
Yes -2 7
Yes -2 7
Yes -2 7
Yes -2 7
Yes -2 7
Yes -1 6
Yes 0 5
Yes -2 3
Yes -2 3
Yes -2 3
Yes -2 3
Yes -2 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
-3 4
-3 4
Yes 0 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes -1 6
Yes 0 5
