Specifications

9 Specifications

9.1 Electrical Data

9.1.1 Mains Supply 3x380–480 V AC
Normal overload
(Normal overload=110% current during 60 s)
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [hp]
Typical shaft output at 480 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 400 V) [A]
Intermittent (60 s overload)
(at 400 V) [A]
Continuous (at 460/480 V) [A]
Intermittent (60 s overload)
(at 460/480 V) [A]
Continuous kVA (at 400 V) [kVA]
9 9
Continuous kVA (at 460 V) [kVA]
Continuous kVA (at 480 V) [kVA]
Maximum input current
Continuous (at 400 V) [A]
Continuous (at 460/480 V) [A]
Maximum number and size of cables per phase (E1h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
- Brake or regeneration [mm
Maximum number and size of cables per phase (E3h)
- Mains and motor [mm
- Brake [mm 2 (AWG)]
- Load share or regeneration [mm
Maximum external mains fuses [A]
Estimated power loss at 400 V [W]
Estimated power loss at 460 V [W]
4)
Efficiency
Output frequency
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
Power card overtemperature trip [°C (°F)]
Fan power card overtemperature trip [°C (°F)]
Active in-rush card overtemperature trip [°C (°F)]
Table 9.1 Technical Specifications, Mains Supply 3x380–480 V AC
74
VLT® HVAC Drive FC 102
2 (AWG)] 1)
2 (AWG)] 1)
2 1)
(AWG)]
2 1)
(AWG)]
1)
2 1)
(AWG)]
2)
3) 4)
3)4)
Danfoss A/S © 01/2017 All rights reserved.
N355 N400
NO NO
355 400
500 600
400 500
E1h/E3h E1h/E3h
658 745
724 820
590 678
649 746
456 516
470 540
511 587
634 718
569 653
5x240 (5x500 mcm) 5x240 (5x500 mcm)
4x240 (4x500 mcm) 4x240 (4x500 mcm)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
6x240 (6x500 mcm) 6x240 (6x500 mcm)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
4x185 (4x350 mcm) 4x185 (4x350 mcm)
800 800
6928 8036
5910 6933
0.98 0.98
0–590 Hz 0–590 Hz
110 (230) 110 (230)
80 (176) 80 (176)
85 (185) 85 (185)
85 (185) 85 (185)
85 (185) 85 (185)
N460
NO
450
600
530
E1h/E3h
800
880
730
803
554
582
632
771
704
5x240 (5x500 mcm)
4x240 (4x500 mcm)
2x185 (2x350 mcm)
6x240 (6x500 mcm)
2x185 (2x350 mcm)
4x185 (4x350 mcm)
800
8783
7969
0.98
0–590 Hz
110 (230)
80 (176)
85 (185)
85 (185)
85 (185)
