To Delete A Nat/Pat Policy; Firewall Configuration - 3Com OfficeConnect 3CR100A97 User Manual

8 - 10 C 8: A
HAPTER DVANCED
To Delete a
NAT/PAT Policy
Firewall
Configuration
C F
ONFIGURATION EATURES
want to use Address Translation on the LAN port of the OfficeConnect
Gateway. Select NAT or PAT to apply NAT or PAT to the LAN port.
SUPERNAT makes optimal use of available IP addresses by enabling the
system to automatically switch between PAT and NAT when multiple
IP addresses are assigned to the OfficeConnect Gateway. Select
SUPERNAT if you want the OfficeConnect Gateway to determine
when it is best to use NAT or PAT.
Intelligent PAT
I
Select the appropriate option (Disabled, Enabled) from the Intelligent
PAT drop-down. When Intelligent PAT is enabled, it will intelligently
attempt to determine where an unsolicited incoming packet should be
delivered
2 Select the name of the NAT Policy you want to modify from the NAT
Policy Name drop-down menu.
3 Modify the appropriate fields for your NAT/PAT Policy.
4 When you finish making your modifications, click Apply and then click
SaveAll on the OfficeConnect Gateway menu bar to permanently save
your changes.
To delete a NAT/PAT Policy, perform the following steps:
1 Select Delete from the NAT Policy Edit Mode drop-down menu.
2 Select the name of the NAT Policy you want to delete from the NAT Policy
Name drop-down menu.
3 Click the Delete button and click OK when the system prompts you to
verify that you want to delete the policy.
4 Click Apply and then click SaveAll on the OfficeConnect Gateway menu
bar to permanently save your changes.
The Firewall Configuration page lets you configure or modify the packet
filtering firewall options used by the OfficeConnect Gateway. Packet
filters are used primarily in networks that cross organizational or
corporate boundaries. They control inter-network data transmission by
accepting or rejecting the passage of specific packets through network
interfaces based on packet header information.
