9 - 6 C 9: M
HAPTER ANAGEMENT

Console Telnet

F
EATURES

To Modify a Command Script

8 To modify a Command Script, select the name of the script in the File
Name drop-down menu.
9 Modify the script as needed in the Command Lines window.
10 Click Apply after you complete your modifications to the command
script.
11 Click SaveAll on the upper right portion of the OfficeConnect Gateway
menu bar to permanently apply and save your changes.

To Delete a Command Script

12 To delete a Command Script, select the name of the script in the File
Name drop-down menu.
13 Click Delete.
14 The system will prompt you to verify that you want to delete the script.
Click OK.
15 Click Apply after you complete your modifications to the command
script.
16 Click SaveAll on the upper right portion of the OfficeConnect Gateway
menu bar to permanently apply and save your changes.
To configure and manage the OfficeConnect Gateway manually via the
CLI (command line interface), you must establish a Telnet console
connection with the OfficeConnect Gateway.
To establish a Telnet Console connection with the OfficeConnect
Gateway, perform the following steps:
1 From your web browser, access the OfficeConnect Gateway page
(Default IP address: 192.168.1.1).
The Configuration options are displayed on the left-hand frame of the
OfficeConnect Gateway page.
2 Click Console Telnet (located in the Management section of the left-hand
frame) to access the Console Telnet page.
