8 - 30 C 8: A
HAPTER DVANCED
To Modify a
VPN Configuration
C F
ONFIGURATION EATURES
14 Select an IP Protocol (All, TCP, or UDP) from the IP Protocol drop-down
menu. If you select TCP or UDP, the page will dynamically change to
display the Client IP and Peer IP Port fields.
If you selected TCP or UDP, select the appropriate category (Allow all
Ports or Filter Port) for the Client and Peer IP Ports. If you select Filter
Port, the system will display a text box for entering the Port Number
you want filtered.
Select a security level (Minimum, Maximum, or Custom) from the
Security Level drop-down menu. If you select Minimum or Maximum,
the OfficeConnect Gateway will utilize its default security settings for
each level.
If you select Custom, a separate Advanced IPSEC Settings window will
be displayed below the VPN Tunnel Configuration window. Use this
window to set up your custom IPSec parameters for your VPN Tunnel.
To customize the IPSEC Settings for your VPN, refer to Configuring
your IPSEC Settings section on page 8-22.
15 If you selected Minimum or Maximum for your Security level, click Apply
and then click SaveAll on the OfficeConnect Gateway menu bar to
permanently save your VPN tunnel configuration information.
To modify a VPN Configuration, perform the following steps:
1 Select Modify from the Edit Mode drop-down menu.
2 Select the name of the VPN Tunnel you want to modify from the VPN
Name drop-down menu.
3 Modify the appropriate fields for your VPN Configuration.
4 Click the Apply button when you have made all necessary modifications
and then click SaveAll on the OfficeConnect Gateway menu bar to
permanently save your changes.
