8 - 22 C 8: A
HAPTER DVANCED
To Create a VPN
Configuration using
IPSec
C F
ONFIGURATION EATURES
6 Select a data compression algorithm from the Compression drop-down
menu. The default value is Auto.
7 Select a workstation from the Workstation list. To select all workstations
on the LAN subnet of the OfficeConnect Gateway, click the All
Workstations checkbox.
8 Click Apply. Then click Finish on the next screen that is displayed to access
the VPN Route Configuration page.
9 Configure a route for your VPN as described in the VPN Route
Configuration section of this chapter.
The IPSec Tunneling Protocol (IPSec) is a widely used VPN tunneling
protocol that provides security services at the IP layer by enabling a
system to select required security protocols, determine the algorithm(s) to
use for the service(s), and put in place any cryptographic keys required to
provide the requested services.
To create a VPN tunnel using the IPSec protocol, perform the following
steps:
1 Select Create from the Edit Mode drop-down menu.
2 Enter a name for the VPN Tunnel you want to create in the VPN Name
field.
3 Select IPSEC in the VPN Protocol drop-down menu.
4 Enter the Shared Secret (password) for the VPN Tunnel in the Shared
Secret field.
5 Select an attachment layer (WAN Interface or PPP Profile) for the VPN
tunnel from the Attachment Layer drop-down menu. The VPN
Configuration page will dynamically change based on your selection.
If you selected WAN Interface as your attachment layer, select the
appropriate WAN interface in the Attachment Interface drop-down
menu.
If you selected PPP Profile as your attachment layer, select the appropriate
PPP profile in the Attachment Profile drop-down menu.
A PPP Profile must exist. If you have not created one, the system will
prompt you to create one.
6 Enter the IP address of the Remote Security Gateway in the Remote
Gateway field.
