4 Click Properties.
The Local Area Connection Properties window opens.
5 Select Internet Protocol (TCP/IP) and click Properties.
The Internet Protocol (TCP/IP) Properties window opens.
6 Write down the values listed in the IP Address, Subnet Mask and
Default Gateway fields. You will need to reenter this information later.
7 Change the IP Address, Subnet Mask and Default Gateway fields as
follows (this allows your workstation to be recognized by the
OfficeConnect Gateway):
In the IP Address field, enter 192.168.1.2
I
In the Subnet Mask field, enter 255.255.255.224
I
In the Default Gateway field, enter 192.168.1.1
I
8 Click OK to close the Internet Protocol (TCP/IP) Properties window.
9 Click OK to exit the Local Area Connection Properties window.
10 Click Close to exit the Local Area Connection Status window.
You may be prompted to re-boot your workstation.
Your workstation has now been set up to temporarily access the
OfficeConnect Gateway. You are ready to continue on and install and
configure the OfficeConnect Gateway as described in the OfficeConnect
Gateway Quick Start Guide.
11 You must now change the default IP address of the OfficeConnect
Gateway to recognize your statically configured workstation. From the
OfficeConnect Gateway web page, click LAN Configuration (located in
the Network section of the left-hand frame) to access the LAN
Configuration page.
Using the Gateway in a Static IP Environment 2 - 5
