6 - 8
C
6: WAN C
HAPTER
RFC 1483-MER Static
Configuration
ONFIGURATION
routing is selected, the OfficeConnect Gateway acts as a router and all IP
traffic is routed to the remote hosts.
You can create, modify and delete your RFC 1483-MER WAN
Configurations. Refer to the Modifying Your WAN Protocols section in
this chapter for information on how to modify your currently configured
WAN protocols. If you want to delete a configured WAN protocol, refer
to the Deleting Your WAN Protocols section.
To configure your WAN settings for an RFC 1483-MER Static
Configuration, perform the following steps:
Forwarding Mode: Routing
1 Select Create from the PVC Name Edit Mode drop-down menu. If no
WAN interface has previously been configured, the field will already be
set to Create.
2 Enter a name for your PVC (Permanent Virtual Circuit) in the PVC Name
field. This is the name for the WAN you are configuring. The PVC is the
circuit that will be used to form the connection between the LAN and
WAN sides of the OfficeConnect Gateway.
3 Select RFC 1483-MER from the WAN Protocol drop-down menu.The
WAN Configuration page will dynamically change as shown in the
following illustration.
