8 - 6
C
8: A
HAPTER
DVANCED
To Create a NAT Static
or Dynamic Policy
C
F
ONFIGURATION
EATURES
The following sections describe how to configure the following NAT/PAT
options:
Create a NAT Static or Dynamic Policy
I
Create a PAT Static Policy
I
Create a PAT Dynamic Policy
I
Modify a NAT/PAT Policy
I
Delete a NAT/PAT Policy
I
The OfficeConnect Gateway is factory configured with basic default NAT
and PAT Policies (for NAT: default_NAT; for PAT: default_TCP and
default_UDP). The default PAT policy for PPTP always has the Private Net
Mask field set to 255.255.255.0.
To create a NAT Static or Dynamic policy, perform the following steps:
1 Select Create from the NAT Policy Edit Mode drop-down menu.
2 Enter a name for the NAT Policy you want to create from the NAT Policy
Name field.
A policy identifies the specific NAT/PAT configuration you create for a
configured WAN interface.
3 Select a policy type (NAT Static or NAT Dynamic) from the NAT Policy Type
drop-down menu.
Select NAT Static to permanently map a private address to a public
address. Select NAT Dynamic to dynamically map a pool of private IP
addresses to a public address. (Note: a dynamic NAT policy can be
mapped to a public address or to a pool of public addresses).
4 Enter an IP address in the Private Start Address field. This is the first
address of the range of addresses available in the public pool for mapping
private workstation addresses to a public network.
5 Enter an IP address in the Private End Address field. This is the last address
of the range of addresses available in the private pool for mapping
private workstation addresses to a public network.
6 Enter an IP address in the Public Start Address field. This is the first
address of the range of pool addresses available to the OfficeConnect
Gateway for assigning IP addresses for use on the WAN side of the
OfficeConnect Gateway connection.
