6 - 14 C 6: WAN C
HAPTER ONFIGURATION
Provider. The other selection, Show Current Users, shows the current user
of a configured PPP WAN.
5 Enter your User Name in the Username field. This is the name that was
provided by your Service Provider.
6 Enter your password in the Password field. This is the password that was
provided by your Service Provider.
7 Enter the VPI (Virtual Port Identifier) Number that was provided by your
Service Provider in the VPI Number field.
8 Enter the VCI (Virtual Circuit Identifier) Number that was provided by your
Service Provider in the VCI Number field.
9 Select RIPv2 (unless instructed otherwise by your Service Provider) from
the IP Routing Protocol drop-down menu.
10 Select Enabled from the Default Route Option drop-down menu if you
want to make this PPP configuration your default route.
11 Select Negotiate or Assign from the Address Selection drop-down menu
to use the dynamic IP addressing default settings of the OfficeConnect
Gateway.
Do not select "Negotiate" if you are configuring a WAN PPTP or L2TP VPN
profile.
If you are using a Static IP Address, select Specified in the Address
Selection drop-down menu. The WAN Configuration page will
dynamically change and display the following additional fields.
Local WAN IP Address:
I
Enter the Local WAN IP address for the OfficeConnect Gateway in the
Local WAN IP Address field. Your Service Provider will give you this
address.
Remote WAN IP Address:
I
Enter the Remote WAN IP address for the OfficeConnect Gateway in
the Remote WAN IP Address field. Your Service Provider will give you
this address. The Remote WAN IP Address is the IP address of the
Service Provider's server you will be connecting to.
WAN IP Mask
I
Enter the IP address of the WAN IP Mask in the WAN IP Mask field.
Your Service Provider will provide this information. The WAN IP Mask
is used together with the IP address to determine whether or not IP
