OfficeConnect
Gateway Web page
Conventions
Configuring the
OfficeConnect
Gateway
The following web page conventions are used on the web pages of the
OfficeConnect Gateway:
Field Description Labels:
Bold
I
Indicates a required field or value.
Normal
I
Indicates an optional field or value.
Buttons on the web pages
I
The buttons used on the web pages allow you to control the
navigation and operation as follows:
Apply
I
Sets the current page values. (Note: To save the values
permanently, you still must click SaveAll on the OfficeConnect
Gateway menu bar.)
Reset
I
Resets the current page values. (To the Default values if in Create
mode. To the last saved values if in Modify mode.)
Help
I
Display detailed help for the current page.
The Help conventions used for the field descriptions are:
Hover
I
Moving the mouse (or pointing device) over the field description
displays a one line message on the status bar at the bottom of your
browser's window.
Click
I
Clicking on the field description launches the help page for the field.
To configure the settings of the OfficeConnect Gateway, click Configure
on the menu bar to access the Configuration frame on the left-hand
frame of the OfficeConnect Gateway web page. The following
Configuration categories are displayed in the left-hand frame of the
page:

Configuring the OfficeConnect Gateway

3 - 5
