To Create a PAT Static
Policy
7 Enter an IP address in the Public End Address field. This is the last address
in the range of pool addresses available.
8 Select a WAN interface from the NAT Policy Interface Name drop-down
menu. This list shows all configured WAN interfaces. If there are none,
the text "None Configured" will be displayed in this drop-down menu.
You must configure a WAN interface before you can apply a NAT or PAT
policy to it.
9 Click the Apply button when you have made all necessary modifications
and then click SaveAll on the OfficeConnect Gateway menu bar to
permanently save your changes.
To create a PAT Static policy, perform the following steps:
1 Select Create from the NAT Policy Edit Mode drop-down menu.
2 Enter a name for the NAT Policy you want to create from the NAT Policy
Name field. A policy identifies the specific NAT/PAT configuration you
create for a configured WAN interface.
3 Select PAT Static from the NAT Policy Type drop-down menu.
4 Enter an IP address in the Private Address field. This is the IP address of a
workstation on the LAN side of the OfficeConnect Gateway.
5 Enter an IP address in the Public Address field. This is the IP address that
will be used by the workstations on the LAN to accessing the WAN side of
the OfficeConnect Gateway.
6 Select a port type (TCP/UDP) from the Port Type drop-down menu.
7 Enter the appropriate port number in the Public Port field. This is the port
that allows public access to the WAN.
8 Select a WAN interface from the NAT Policy Interface Name drop-down
menu. This list shows all configured WAN interfaces. If there are none,
the text "None Configured" will be displayed in this drop-down menu.
You must configure a WAN interface before you can apply a NAT or PAT
policy to it.
9 Click the Apply button when you have made all necessary modifications
and then click SaveAll on the OfficeConnect Gateway menu bar to
permanently save your changes.
NAT/PAT Configuration 8 - 7
