cable into the port without regard to its direction. Figure 5-1 shows the ports, and Table 5-1
describes the port pins.
Pin
1
2
3
4
5
6
7
8
4. State indicators
The EtherNet/IP communication card provides four LED indicators and four net port indicators
to indicate its states. Table 5-2 describes the state indicators.
LED Color
LED1 Green
LED2 Green
LED3 Red
LED4 Red
Figure 5-1 Two standard RJ45 ports
Table 5-1 Standard RJ45 port pins
Name
TX+
TX-
RX+
n/c
n/c
RX-
n/c
n/c
Table 5-2 State indicators
State
On
Blinking (1Hz)
Off
On
Blinking (1Hz)
Off
On
Blinking (1Hz)
Blinking (2Hz)
Blinking (4Hz)
Off
On
EtherNet/IP communication card
Description
Transmit Data+
Transmit Data-
Receive Data+
Not connected
Not connected
Receive Data-
Not connected
Not connected
Description
The card is shaking hands with the VFD.
The card and VFD communicate normally.
The card and VFD communicate improperly.
The communication between the card and PLC
is online and data interchange is allowed.
IP address conflict between the card and PLC.
The communication between the card and PLC
is offline.
Failed to set up I/O between the card and PLC.
Incorrect PLC configuration.
The card failed to send data to the PLC.
The connection between the card and PLC
timed out.
No fault.
3.3V power indicator.
