Example of PDO1
The VFD is a Goodrive350 series VFD, and the slave station address is 3. Assume that you
want to set the function code P15.13 of the VFD to 1.
Command analysis: The parameter address of P15.13 is 0×0F0D. According to the protocol,
the request code of PDO1 Rx is 0×02, the parameter address is 0x0F0D, and the requested
data is 0x01, and therefore PDO1 Rx transmitted by the master station is as follows.
COB-ID
0x203
If the VFD parameter is successfully modified, the following PDO1 Tx command is returned.
Response
COB-ID
Byte0
0x183 0x01

3.5.3 PDO2 Rx

PDO2 Rx is used to modify CWs and real-time process data (setting 1, setting 2, and setting 3)
of a VFD. A CW is used to control the start and stop of a VFD, and settings are used to control
the real-time running values of the VFD, such as set frequency.

Command
Master station -> slave station
COB-ID
0x300+NODEID

Description
A CW is two bytes. Byte0 is the LSB, and Byte1 is the MSB. Table 3-17 describes
Goodrive350 series VFD CWs.
Bit
Communication-based
0–7
control command
A user password is set, and the master station does not
provide the password to unlock the system when
performing a read or write operation. The error of system
locked is reported.
Request code
Byte0 Byte1
0x02 0x00
code
Byte1 Byte2
0x00 0x00
Byte0 Byte1
CW
0x2101.00
Table 3-17 Goodrive350 series VFD CWs
Name
Parameter address
Byte2
0x0D
Error code Response data
Byte3 Byte4
0x00
Byte2 Byte3
Setting 1
0x2100.03
Value
1
2
-34-
CANopen communication card
Definition
Requested data
Byte3 Byte4
0x0F 0x01
Byte5
0x01 0x00
Byte4 Byte5
Setting 2
0x2100.04
Description
Forward running
Reverse running
Byte5
0x00
-
Byte6 Byte7
0x00 0x00
Byte6 Byte7
Setting 3
0x2100.05
