INVT Goodrive350 Series Operation Manual page 121

Communication extension card
Function
Name
code
Setting mode of
upper frequency
P03.15 limit of reverse
running in torque
control
Setting mode of
upper limit of
P03.18
electromotive
torque
Setting mode of
P03.19 upper limit of
brake torque
Voltage setting
P04.27
channel
Parameter description
9: Reserved
10: EtherCAT/PROFINET/EtherNetIP
communication
11–12: Reserved
0: Keypad (P03.17)
1–6: Reserved
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Reserved
10: EtherCAT/PROFINET/EtherNetIP
communication
11–12: Reserved
0: Keypad (P03.20)
1–5: Reserved
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Reserved
9: EtherCAT/PROFINET/EtherNetIP
communication
10–11: Reserved
0: Keypad (P03.21)
1–5: Reserved
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Reserved
9: EtherCAT/PROFINET/EtherNetIP
communication
10–11: Reserved
0: Keypad (P04.28)
1–7: Reserved
8: PROFIBUS/CANopen/DeviceNet
communication
9: Ethernet communication
10: Reserved
11: EtherCAT/PROFINET/EtherNetIP
communication
12–13: Reserved
-116-
Related function codes
Setting Default
range value
0–12 0
0–11 0
0–11 0
0–13 0
