INVT Goodrive350 Series Operation Manual page 122

Communication extension card
Function
Name
code
P06.01 Y1 output
P06.02 HDO output
Relay output
P06.03
Relay output
P06.04
Analog output
P06.14
HDO high-speed
P06.16
pulse output
Type of current
P07.27
0: Invalid
1–23: Reserved
24:
communication virtual terminal output
RO1
25: Ethernet communication virtual
terminal output
26–33: Reserved
34: EtherCAT/PROFINET/EtherNetIP
RO2
communication virtual terminal output
35–63: Reserved
0: Running frequency
1–15: Reserved
AO1
16:
communication setting 1
17:
communication setting 2
18: Ethernet communication setting 1
19: Ethernet communication setting 2
20: Reserved
21: EtherCAT/PROFINET/EtherNetIP
communication setting 1
22–26: Reserved
27: EtherCAT/PROFINET/EtherNetIP
communication setting 2
28–47: Reserved
0: No fault
29: PROFIBUS communication fault
(E-DP)
30: Ethernet
(E-NET)
31: CANopen
(E-CAN)
fault
57: PROFINET communication timeout
fault (E-PN)
58: CAN communication timeout fault
(ESCAN)
60: Card identification failure in slot 1
(F1-Er)
Parameter description
PROFIBUS/CANopen/DeviceNet
PROFIBUS/CANopen/DeviceNet
PROFIBUS/CANopen/DeviceNet
communication
communication
-117-
Related function codes
Setting Default
range value
0–63
0–63
0–63
0–63
0–47
0–47
fault
fault
/
0
0
1
5
0
0
/
