INVT Goodrive350 Series Operation Manual page 132

Communication extension card
Function
Name
code
Transmitted
P16.43
Transmitted
P16.44
Transmitted
P16.45
Transmitted
P16.46
Transmitted
P16.47
Transmitted
P16.48
Transmitted
P16.49
Transmitted
P16.50
Transmitted
P16.51
PZD10
11: Voltage setting (for V/F separation)
(0–1000, in which 1000 corresponds to
100.0% of the rated voltage of the
motor)
12: AO output setting 1 (-1000–+1000,
in which 1000 corresponds to 100.0%)
13: AO output setting 2 (-1000–+1000,
in which 1000 corresponds to 100.0%)
14: MSB of position reference (signed
number)
15: LSB of position reference (unsigned
number)
16: MSB of position feedback (signed
number)
17: LSB of position feedback (unsigned
number)
18: Position feedback setting flag
(position feedback can be set only after
this flag is set to 1 and then to 0)
19–31: Reserved
0: Invalid
PZD2
1: Running frequency (×100, Hz)
2: Set frequency (×100, Hz)
PZD3
3: Bus voltage (×10, V)
4: Output voltage (×1, V)
PZD4
5: Output current (×10, A)
6: Actual output torque (×10, %)
PZD5
7: Actual output power (×10, %)
8: Rotating speed of the running (×1,
PZD6
RPM)
9: Linear speed of the running (×1, m/s)
PZD7
10: Ramp frequency reference
11: Fault code
12: AI1 value (×100, V)
PZD8
13: AI2 value (×100, V)
14: AI3 value (×100, V)
PZD9
15: HDIA frequency (×100, kHz)
16: Terminal input state
Parameter description
-127-
Related function codes
Setting Default
range value
0–31 0
0–31 0
0–31 0
0–31 0
0–31 0
0–31 0
0–31 0
0–31 0
0–31 0
