INVT Goodrive350 Series Operation Manual page 127

Communication extension card
Function
Name
code
P15.28 communication
address
CAN baud rate
P15.29
setting
P15.30 communication
timeout time
DeviceNet
P15.31 communication
timeout time
Displayed node
P15.32
baud rate
P15.33 Enable polling
Output instance
P15.34
in polling
Input instance in
P15.35
polling
3: 250 kbps
4: 125 kbps
5: 100 kbps
6: 50 kbps
7: 20 kbps
CAN
0–127
0: 50 kbps
1: 125 kbps
2: 250 kbps
3: 500 kbps
4: 1 Mbps
CAN
0.0 (invalid)–300.0s
0.0 (invalid)–300.0s
0
0–1
19: INVT VFD output
20: ODVA basic speed control output
21: ODVA extended speed control
output
22: ODVA speed and torque control
output
23: ODVA extended speed and torque
control output
24: INVT basic speed control output
25: INVT extended speed control output
26: INVT speed and torque control
output
27: INVT extended speed and torque
control output
69: INVT VFD input
70: ODVA basic speed control input
71: ODVA extended speed control input
Parameter description
-122-
Related function codes
Setting Default
range value
0–127 1
0–4 1
0.0–300.
0.0s
0
0.0–300.
0.0s
0
0 0
0–1 1
19–27 19
69–77 69
