localIp0 nnn.nnn.nnn.nnn
Example: 192.168.0.51
mode enable/disable/standby
Example: enable
name Name: channel
Example: 5ch_Device1:2
source_device Serial number:
channel or none
Example: 50001:2
source_mode Text string
Example: 1280x720 60p
source_status active/unplugged/
null
Example: active
srcIp nnn.nnn.nnn.nnn:nnnn
Example:
192.168.0.23:8000
status active/no device
Example: active
type source/display/
recorder/swdecoder
none
Example: swdecoder
userParam1 Text string
Example: Group1
userParam2 Text string
Example: Group2
userParam3 Text string
Example: Group3
For the following examples:
VNM 200 (Source): Name = 200_Device1, ID = 20001, IP = 192.168.0.21
VNM 200 (Source): Name = 200_Device2, ID = 20002, IP = 192.168.0.22
VNM 200 (Display): Name = 200_Device3, ID = 20003, IP = 192.168.0.23
Name = 200_Device4, ID = 20004, IP = 192.168.0.24
VNM 200 (Display):
VNS 104: Name = 104_Device1, ID = 40001, IP = 192.168.0.41
Example 1 - List all device names.
getdevices keys=name
Returns:
["200_Device1","200_Device2","200_Device3","200_
Device4","104_Device1","104_Device1:1","104_Device1:2","104_
Device1:3","104_Device1:4"]
Example 2 - List all device names and firmware versions.
getdevices keys=name,curver
Returns:
[{"name":"200_Device1","curver":"ver3.11.0"},{"na
me":"200_Device2","curver":"ver3.11.0"},{"name":"200_Device3",
"curver":"ver3.11.0"},{"name":"200_Device4","curver":"ver3.11.
0"},{"name":"104_Device1","curver":"ver1.0.0"},{"name":"104_De
vice1:1","curver":"ver1.0.0"},{"name":"104_Device1:2","curver"
:"ver1.0.0"},{"name":"104_Device1:3","curver":"ver1.0.0"},{"na
me":"104_Device1:4","curver":"ver1.0.0"}]
IP address of Ethernet port 0 on the device.
The current operating mode of the device.
The user-defined name of the device
followed by the channel number if
applicable (VNM Recorder and VNS104).
The device ID of the video source
associated with this device, if applicable.
The current video mode of the device.
Indicates status of the video input of a
source device. Null in the case of a display
device.
Stream source IP address and port number.
Indicates a device is present (active) or
unreachable (no device) on the system.
Current device type configuration. Where a
codec device has yet to be provisioned as
a source or display, 'none' is returned.
User text field.
User text field.
User text field.
]
]
