Device Attributes

When a device is placed in the Preset Design workspace, the Device Attributes
panel (see figure 80) provides access to preset-specific device settings available to the
preset manager.
When the device is selected, an appropriate set of attributes for that device populates the
device attributes panel. Attributes customize the device for a specific function within that
preset and are a subset of the full configuration control set available in the device list view
(see
Device Attributes
Name
Directory
File
Launch Status
Repeat
Time Sync
Start Offset
Stop Offset
File Length
Figure 80.
The Device Attributes configuration panel populates according to the selected
device and its function in the preset. The following information details configuration options
available in the attribute panel for each device.
Device Attributes – Codecs
Device attributes change depending on the role of the codec in the preset (see Device
Attributes – Encoders, and Device Attributes – Decoders on the following pages).
Device Attributes – Encoders
Only the VNE 250 has attributes configurable by the preset manager. The attribute panel for
the other encoder devices contain only a read-only Name field.
Figure 81.
1
Devices Page Features
on page 39).
VN_Recorder_5CH:1
/Test1/
diff1
Play
No
Yes
00:00:00
00:07:02
00:07:02
Preset Manager, Device Attributes (Player)
Device Attributes, VNE 250
Name — Read-only field for the device name taken from the device list.
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
VNM EC 200 • Preset Manager 101
