Deleting Formats

NOTES:
To delete a custom resolution format, select a resolution and click Delete located at the
lower right corner of the Format Editor page (see figure 152,

Source Format Editor

To view or change the properties of a source format:
1.
2.
3.
4.
Figure 152.
Source Format panel
To create a new source format, modify the desired fields:
•
•
•
•
•
•
•
•
•
The default resolutions provided with the VNM EC 200 cannot be deleted.
• Custom resolutions that are in use by any active VN-Matrix device cannot be
deleted.
Click the right tab, (see figure 152,
Click the Format Editor tab (
The Format Editor page opens.
Click the Source Formats bar to open a list of source formats (
Select the desired source format (
listed in the Source Format panel on the right (
1 1
3 3
4 4
Source Resolution Properties
( )
5
Line Count — Specify the number of horizontal lines of information.
Line Period (ms) — Specify how often the horizontal lines of information are updated.
Pixels Per Line — Specify how many pixels are used to create each line of information.
HSize — Specify the horizontal resolution (number of pixels wide) from the source.
VSize — Specify the vertical resolution (number of pixels high) from the source.
First Pixel — Specify the position of the first active pixel in the line.
First Line — Specify the position of the first active line in the frame.
Trisync Ignore — Zero for all source types. 100 for source types using tri-level sync.
).
1
).
2
). The properties of the selected resolution are
4
).
5
2 2
5 5
VNM EC 200 • Format Editor Page
below).
