Configuring Dual VNM EC 200s
This section details how to set up and configure dual (redundant) VNM EC 200s.

Configuring the Network Settings (Eth0)

NOTES:
Each VNM EC 200 is pre-configured with the following network settings.
IP address:
Subnet mask: 255.255.255.0
Gateway:
MTU:
NOTES:
In the following examples:
•
•
•
Use the following procedure to change the network settings of each VNM EC 200.
1.
2.
• The VNM EC 200s should not be paired when configuring the network settings.
For information on how to unpair previously paired VNM EC 200s, see
controllers on page 177.
• Be aware that unpairing and then pairing a VNM EC 200 deletes device
configuration files, presets, and custom input or output modes.
• Each VNM EC 200 must use an IP address that contains the same network prefix
(for example: 192.168.xxx.xxx) and subnet.
• Each VNM EC 200 must use the same subnet mask address.
192.168.254.254
192.168.254.1
1500
• With these default settings, devices connected to the VN-Matrix network must use
IP addresses within the range of 192.168.254.2 through 192.168.254.253 and use
the same subnet mask.
• Each VNM EC 200 has a default IP address of 192.168.254.254. This IP must be
changed on one of the EC 200s before configuration for dual operation.
VNM EC 200 #1 is the redundant primary and has an IP address of
192.168.254.254.
VNM EC 200 #2 is the redundant secondary and has an IP address of
192.168.254.253.
The cluster IP address is 192.168.254.250.
Connect only ONE VNM EC 200 to the network the PC controller is connected to.
Log into the VNM EC 200 (see
page 11) using the default settings.
VNM EC 200 • Dual (Redundant) Controller Configuration
Accessing the Web‑based User Interface
Unpairing
on
162
