Alarm Type Reference Tables

Encoders

CLI Alarm
NOSRC
BADSRCSYN
NOSDILOCK
NOSDIMODE
NOMODE
BADSRC
PHASING
HWNOVIDEO
UNSUPAUDIOSRC
BADAUDIOSRC
VIDEOOVERLOAD
NWOVERLOAD
BADREVAUDIO
Alarm Description Fault Description
No Source No input source is connected.
Bad Source Syncs An input source is connected
but the sync timing is not
recognized
source due to bad sync
measurements).
No SDI Source Lock An SDI source is connected
but the signal timing is not
recognized.
(An SDI source is present but the
PLL lock failed).
Unsupported SDI The connected SDI source
Mode mode not supported.
Unsupported Mode The connected source is not
supported; a user-mode must
be created.
Bad Source A source is connected and
syncs have been detected, but
it is not possible to make active
pixel measurements.
Analog Phasing Failure The analog pixel clock auto-
phasing process failed.
Hardware Encoding The hardware is unable to
Error encode the input video.
Unsupported Audio The digital audio source has a
Source bad or unsupported clock rate.
Bad Audio Source The audio source is not valid
for the current video source.
Data Rate Overload The system is not able to
process the source at the
current settings; increase the
compression.
(The compressed data rate is too
high, increase the compression).
Network Overload The network is dropping too
many packets.
Bad Reverse Audio The reverse audio channel
contains no data or has a large
number of dropouts.
Alarm Type
Critical, Reporting
Critical, Reporting
(unable to input
Critical, Reporting
Critical, Reporting
Critical, Reporting
Critical, Reporting
Warning, Reporting
Critical, Reporting
Critical, Reporting
Warning, Reporting
Critical, Reporting
Warning, Reporting
Warning, Reporting
VNM EC 200 • Alarms 158
