Misc Menu

This menu contains four selections for the VND 250 and three for the VNE 250 (see
figure 57).
• Real‑time Bandwidth Monitor (VND 250)
Delete Device
•
• OSD Identifier Editor
• Send HLI Command
Figure 57.
Real-time Bandwidth Monitor (VND 250)
Select the real-time bandwidth monitor (see figure 57,
monitors the bandwidth (measured in Mbps) used by the selected device or devices (see
figure 58).
Figure 58.
NOTE: Bandwidth data is displayed only for decoder devices. A graph is displayed for
an encoder, but the data always shows
Delete Device
Select this option (
NOTES:
• Be certain the appropriate devices are selected when using this menu option. The
selected devices are deleted right away; no notification or warning is given when the
option is selected.
• A device can only be deleted when it is offline. Active devices cannot be removed
from the device list.
1 1
2 2
3 3
4 4
VNM 250 Misc Menu
VND250_Dec
Bandwidth Monitor
) to delete the selected device or devices.
2
VNM EC 200 • Device Configuration and Control
) to open a new dialog box that
1
Kbps.
