License Menu

Click License to open the Device License Management dialog box. This dialog
displays enabled features for the selected unit and enables optional features (see figure 56).
1
2
3
4
5
6
7
Figure 56.
NOTE: The Licensed Features panel and Current Structure panel fields are
read-only (cannot be edited).
Licensed Features panel
The Licensed Features panel details the features currently enabled on the device.
Video — Indicates the input signal format type.
1
Audio — Indicates the number of supported audio channels.
2
Video Scaler (VND 250 only) — Indicates whether video scaling is enabled or
3
disabled.
Whiteboard — Indicates whether whiteboard data streaming is enabled or disabled.
4
Data — Indicates whether data streaming is enabled or disabled.
5
Current Structure panel
The Current Structure panel details the current structure code and its corresponding
checksum. These are read-only (cannot be edited) fields.
Structure — Shows the current feature set of the selected device. The values in this
6
code correspond to the active features displayed in the Licensed Features panel.
Checksum — Shows the checksum value used to enable the structure code.
7

Upgrade Menu

Click Upgrade to open the
firmware (see
ATTENTION:
• Ensure that compatible firmware is used to upgrade the selected VN-Matrix devices.
• Assurez vois qu'un firmware compatible est utilisé pour mettre à jour les appareils
VN-Matrix sélectionnés.
• Upgrading with incorrect firmware can cause the VN-Matrix devices to stop
responding.
• Mettre à jour avec un firmware incorrect peut faire en sorte que les appareils
VN-Matrix arrêtent de répondre.
VND 250 (Left) and VNE 250 (Right) License Menu
Upgrade Device Firmware
Upgrade Menu (2xx and 3xx Devices)
VNM EC 200 • Device Configuration and Control
1
2
4
5
6
7
dialog box used to upgrade the
on page 62).
