Switch EDID menu
Select 'Switch EDID..' menu items with the left ◄ and right ►
buttons and then press ENTER  to step in the submenu.
The emulated EDIDs can be changed in this menu. Dynamic,
User or Factory EDIDs can be selected in the top row with the
up ▲ and down ▼ buttons. The preferred resolution of the
selected EDID is shown in the second row of the screen.
Press left ◄ or right ► button then select the input port with
the up ▲ and down ▼ buttons.
After the desired EDID and input port is selected press the ENTER  button to change
the emulated EDID.
The 'Operation is progress' message appears on the LCD. If switching the EDID succeed
then the 'Operation done!' message is shown for 2 seconds.

5.4.6. Signal Present mode

To enter or exit this mode you have to press the SIGNAL
PRESENT button. Signal present mode is active when Signal
present button is illuminated.
In this mode the source and destination buttons show the
actual connection state of the corresponding port. Press any
SOURCE or DESTINATION button, and detailed information
of that port can be checked on the LCD menu. (Resolution,
refresh rate, type of the video signal)
Source and destination buttons
If a source button is illuminated then a signal is present on that source. If a destination
button is illuminated then a powered display is attached to this output (Hot Plug Detect
signal is present). You can quickly check the cable connections with this feature.
Section 5. Operation
UMX4x4-Pro2
User's Manual
Switch EDID..
EDID Sw F17>E02
LWR 1920x1080@60
Output 1 Video
No signal
Input 2 Video
1920x1200p60 DVI
