7.5.2. Tile view

Tile view is a different approach to display the input and output ports by tiles. Each tile
means an input or output port and additionally shows the most important port and signal
information. Thus, user can check the status of many ports at the same time without
clicking on a port or opening port settings window.
Three display modes are defined in Tile view for UMX4x4-Pro2 matrices:
1
2
3
Input ports
1
2 Output ports
3 Page indicator
Selected port
4
5 Connected port(s)
Page 60 / 136

View mode,

Input switch mode and

Output switch mode.
Figure 7-6. Tile view in Crosspoint menu
Section 7. Software control –Lightware Device Controller and Web
Each tile represents an input port.
Each tile represents an output port.
Current page is displayed with green dot. (In case of
UMX4x4-Pro2 there is only one page.)
Last selected port is displayed with yellow background on
the port bar. Press the button to open port settings window.
Those ports are listed (with white background) on the port
bar, which are connected to the Selected port.
4
5
