8.12. RICOD related commands

Important! RICOD works only with the Lightware protocol. The currently used protocol can be
viewed or changed at any time via the matrix front panel (see section
or via protocol commands (see sections 8.4.6,

8.12.1. Set RICOD MASTER status on inputs

Description: Enable or disable the RICOD MASTER status for the selected input port.
Command {:RICOD#<in>@<S/A>I=<A1><A2>;
Response (RICOD#<in>@<S>I=<A1><A2>;
Legend:
Info: The remote lock function takes effect only if RICOD is enabled by <A1>.
Info: If the first character of <A1><A2> is zero, then no command is sent, the RICOD function
is disabled on this input.
Explanation: RICOD control is enabled on the first input port, which unlocks the remote
Section 8. Programmers reference
Format
<B>;<C>;}
<B>;<C>;)CrLf
<in>: Input port number:
Input number in 1 or 2 digit ASCII format (01,3,04 etc.)
<S/A>: Affected ports:
S = single selected input
A = all inputs
<A1> RICOD enable parameter on the input:
1: The RICOD function is enabled to this input port on the local
device (where the command was given).
0: The RICOD function is disabled to this input port on the local
device (where the command was given).
<A2> Remote lock enable parameter:
1: The front panel buttons (in case of transmitters) or the output
(in case of video matrix) is locked on the remote device.
0: The front panel buttons (in case of transmitters) or the output
(in case of video matrix) is unlocked on the remote device.
<B> The selected video input:
"-" (hyphen) = There is no video switch command.
"A" = Automatic input select must be performed on the remote
device if available. (i.e. Autoselect function)
"0" (zero) = The output needs to be muted if available.
(switch to zero)
"1" , "2" , .. , "80" (number between 1 and 80) - Use the given
input number if available.
<C> The selected audio input:
"-" (hyphen) = There is no audio switch command.
"A" = Automatic input select must be performed on the remote
device if available. (i.e. Autoselect function)
"0" (zero) = The output needs to be muted if available.
(switch to zero)
"1","2",..,"80" (number between 1 and 80) - Use the given
input number if available.
device and selects the second video input and the first audio input port on it.
8.4.7 from page 84).
Example
→
{:ricod#1@si=10;2;1;}
←
(RICOD#1@SI=10;2;1;)CrLf
UMX4x4-Pro2
User's Manual
6.1.6 on page 47)
